P. 51

vapor deposition process and 40% attributed to the acrylate   Figure 5. Cable carbon footprint is improved with reduced diameter
          coating. In general, for an optical fiber with smaller coating  optical fiber
          diameter, less coating material is needed, resulting in a
          lower CF of the fiber. In fact, the LCA confirmed that the
          raw material CF of a 125 μm glass diameter and 190 μm
          in coating diameter fiber is 17% less than the raw material
          CF of the standard 242 μm coating diameter fiber with
          similar glass diameter. This represents a 3% reduction
          in overall CF between the two fiber types. As industry
          trends continue to drive towards increased density, reduced
          coating diameter fibers result in a favorable impact in both
          fiber and cable CF.

           Figure 4. Coating diameter reduction impact on optical fiber carbon
           footprint











                                                                 an electricity-intensive process. Process water, thermal
                                                                 energy, and waste have a negligible impact compared to the
                                                                 electricity requirements for manufacturing optical fiber and
                                                                 to the raw materials previously discussed.


                                                                 Corning’s LCA study uses data from relevant factories,
                                                                 which use electricity from the standard grid mix. Since
                                                                 electricity impacts 70-80% of the total optical fiber CF, the
                                                                 value of continued energy efficiency efforts and a greener
          High-performance fibers with reduced coating diameters   electricity mix is clear. Corning is on a path to 100%
          like Corning’s SMF-28? Contour optical fiber portfolio   renewable electricity in the next four to six years in the
          enable increased cable and duct density while reducing   United States and Europe, where most of its optical fiber
          size and materials in cables and solutions. This poses   is manufactured. The impact of renewable electricity was
          yet another opportunity for further improvements in    studied and the LCA confirms that CF can decrease by up
          optical fiber CF. As the impact of raw material is reduced,   to 70% leading to a 0.70 kg CO2eq/km value [9], further
          the fraction of contribution from electricity increases,   improving the current CF advantage over copper-based
          with conversion to renewable electricity providing an   networks by a factor of 3.
          opportunity to significantly reduce cable’s CF.
                                                                 The future is fiber
          Manufacturing impact and contribution of               More than ever, the world depends on data, and optical
          electricity                                            fiber has demonstrated superior capabilities over all other
          Upstream impact of materials is an important part of   alternatives,offering massive capacity that expands the
          Cradle-to-Gate studies, but it does not consider the whole   bandwidth of human potential while reducing power
          picture.The utilities required to convert those materials   consumption and embodied carbon.
          into the final product, optical fiber, were also included in
          the LCA. As previously mentioned, fiber production is   The digital divide persists and to connect the unconnected,

                                                                                                       continuing to page 44
